Prices G055.000047.090.002.039, Type: A55410615.322XX GSR Turkey

BRAND	GSR
Product	G055.000047.090.002.039, Type: A55410615.322XX
Description	Valve
Internal code	OZH3956582
Weight	5
Custom code	84818059
Technical specification	for connection to 230V 50-60HZ consists of: - 055.000047 2/2-way solenoid valve Type: A5541/0615/.322 Control type: directly operated, required delta-p: 0 bar Construction: Poppet valve with nipple seal Function: NC - closed without current Connection: G1/4 nominal size: 1.5 mm pressure: 0 - 330 bar Medium temperature: -40°C/+80°C Ambient temperature: -40°C/+35°C Viscosity max: 22 mm²/s Material (housing): stainless steel 1.4301 (AISI 304) Material (internal parts): stainless steel 1.4104 (AISI 430 F) Seal: PEEK/PTFE Installation position: horizontal or upright drive - B0051.000413 solenoid Type: .322 (K0513239) Voltage: 205 V DC Dust/water protection: IP65 Power: 30 W Duty cycle: 100% ED Connection type: device plug according to DIN 43650-A ISO4400 - B0040.000039 Device plug with bridge rectifier and varistor protection circuit Cable gland: M20x1.5 Connectable cables: diameter 4.5-11 mm max.1.5 mm². : for connection in the appliance plug, only multi-wire conductors according to VDE 0295. : Use class 2 or better Standard: EN 175301-803 Form A/ISO 4400 Housing color: gray

You can find the current prices belongs to GSR - G055.000047.090.002.039, Type: A55410615.322XX coded Valve product. You can provide the all references you look for in endustrial accessories in our company with our unique product range. We are one of the few companies which can present an offer for this product. It produced result of tests of laborotory for years. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.

Where can I buy G055.000047.090.002.039, Type: A55410615.322XX by GSR in Turkey?

You can purchase G055.000047.090.002.039, Type: A55410615.322XX by GSR from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.

What is the price of the G055.000047.090.002.039, Type: A55410615.322XX?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of GSR in Turkey?

While we are not the official distributor or seller of GSR in Turkey, we source our products from reliable channels and offer you original GSR equipment at competitive prices.

How can I access G055.000047.090.002.039, Type: A55410615.322XX catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for G055.000047.090.002.039, Type: A55410615.322XX on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for G055.000047.090.002.039, Type: A55410615.322XX?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
