Prices ZM18RF559(Z-LASER Z20M18S3-F-640-lp90) Z-LASER Turkey

Q: Where can I buy ZM18RF559(Z-LASER Z20M18S3-F-640-lp90) by Z-LASER in Turkey?

You can purchase ZM18RF559(Z-LASER Z20M18S3-F-640-lp90) by Z-LASER from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.

Q: What is the price of the ZM18RF559(Z-LASER Z20M18S3-F-640-lp90)?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Q: Who is the official distributor or seller of Z-LASER in Turkey?

While we are not the official distributor or seller of Z-LASER in Turkey, we source our products from reliable channels and offer you original Z-LASER equipment at competitive prices.

Q: How can I access ZM18RF559(Z-LASER Z20M18S3-F-640-lp90) catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for ZM18RF559(Z-LASER Z20M18S3-F-640-lp90) on our website. Visit our resources section or contact us directly for specific documents.

Q: Do you provide technical support for ZM18RF559(Z-LASER Z20M18S3-F-640-lp90)?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

BRAND	Z-LASER
Product	ZM18RF559(Z-LASER Z20M18S3-F-640-lp90)
Internal code	OZH5150863
Weight	0.085
Technical specification	Z-LASER Z20m18s3-f-640-lp90 SYSTEM SPECIFICATIONS: Wavelength (typ.) 640nm wavelength tolerance ±10nm Wavelength drift (typ.) 0.25nm/K Output power (typ.) 20mW Pointing Stability <15μrad/ °C ± 3% power stability over the entire temperature range APC operating mode Laser class (EN 60825-1) 2M ELECTRICAL SPECIFICATIONS: Supply voltage 5-30VDC Operating current (max.) <400mA Electrical insulation Potential-free housing Connection M12x1 circular connector, 4-pin Power consumption <2,0W OPTICAL SPECIFICATIONS: projection line, homogeneous intensity distribution lp90 optics Opening angle 90° Line straightness < 0.05% DIGITAL MODULATION: Maximum frequency up to 500kHz Rise time <200ns Fall time <100ns Signal level < +0,9V (VIL_max) & > +2.7V (vIH_min) Operating range (VDC) 0-30VDC ANALOG MODULATION: Maximum bandwidth <10Hz 0-1VDC active range Max. voltage range 0-30VDC AMBIENT CONDITIONS: Operating temperature -10°C to +50°C/14°F to +122°F Storage temperature -40°C to +85°C/-40°F to +185°F Relative humidity (max) < 90%, non-condensing Heat loss (max.) <1W MECHANICAL SPECIFICATIONS: M18 industrial housing, chrome-plated brass Net weight 85 g/0.19 lbs diameter 20mm Length 128mm Color black anodized Protection class IP67 24-month warranty

Z-LASER - ZM18RF559(Z-LASER Z20M18S3-F-640-lp90) referenced product produced by high technology.
ZM18RF559(Z-LASER Z20M18S3-F-640-lp90) became irreplaceable of foundations. ZM18RF559(Z-LASER Z20M18S3-F-640-lp90) referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. ZM18RF559(Z-LASER Z20M18S3-F-640-lp90) referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy ZM18RF559(Z-LASER Z20M18S3-F-640-lp90) by Z-LASER in Turkey?

You can purchase ZM18RF559(Z-LASER Z20M18S3-F-640-lp90) by Z-LASER from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.

What is the price of the ZM18RF559(Z-LASER Z20M18S3-F-640-lp90)?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Z-LASER in Turkey?

While we are not the official distributor or seller of Z-LASER in Turkey, we source our products from reliable channels and offer you original Z-LASER equipment at competitive prices.

How can I access ZM18RF559(Z-LASER Z20M18S3-F-640-lp90) catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for ZM18RF559(Z-LASER Z20M18S3-F-640-lp90) on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for ZM18RF559(Z-LASER Z20M18S3-F-640-lp90)?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
