| BRAND | Honsberg |
| Product | UR3K-020GM085 |
| Description | flow switch |
| Internal code | OZH571580 |
| Weight | 0.45 |
| Custom code | 85365080 |
| Technical specification | 940240 - Honsberg location Article number: 90261089 Tipo: UR3K Nominal size: DN 020 Connection: internal thread G 3/4 Case: nickel-plated brass Connection material: nickel-plated brass Pressure resistance: PN 25 Seal: NBR Media temperature: -20.. +110 °C Ambient temperature: -20.. +70 °C Switching range: 6 - 8.5 l/min H2O Switch head: plastic Adjustment: Adjusting screw El. Connection: DIN 43650-A/ISO 4400 plug El. Contact: reed switch Contact capacity: 230 V AC 1 A 50 VA Connection diagram: Closer - No. 0.372 Protection class: IP 65 Flow direction: Horizontal from left |
