Prices UG-5-AFR-24V-ST2 Calectro Turkey

BRAND	Calectro
Product	UG-5-AFR-24V-ST2
Description	air duct smoke switch 24 V AC/DC
Internal code	OZH2002464
Weight	1.5
Custom code	85311030
Technical specification	Calectro duct smoke detector 24 V AC/DC The Calectro duct smoke detector was developed and combined to detect smoke in ventilation ducts a smoke detector with an adapter system, with pipe and housing specifically for optimal airflow were constructed by the smoke detector. The UG-5 can be used on either side of the channel in four different Positions can be installed: 0°, 90°, 180° and 270°. Patented Complete delivery with air duct removal pipe, 0.6 m long. power supply: 24 V AC/DC -15%, +10% Smoke detector type: Optical UG-5-AFR-24V Max. power consumption: 220 mA Operating temperature: -10°C to +55°C Maximum humidity: 99% RH Air velocity range: 1 to 20 m/s Approvals: VdS G213014, CE, prEN-54-27 Smoke alarm release via remote reset Relay output: potential-free Smoke alarm relay: Two 250 V, 8A changeover contacts Service alarm: One 250 V, 5 A changeover contact System fault alarm: One 250 V, 5 A changeover contact Air speed alarm: One 250 V, 5 A changeover contact LED on smoke detector: Green: service alarm (contamination) red - smoke alarm LED on circuit board: Green: normal mode Yellow - system error Yellow - air speed alert Adapter housing: ABS Protection class: IP54

You can find the current prices belongs to Calectro - UG-5-AFR-24V-ST2 coded air duct smoke switch 24 V AC/DC product. You can provide the all references you look for in endustrial accessories in our company with our unique product range. It distinguishes with price and quality among the similar products. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for UG-5-AFR-24V-ST2 Calectro . Make an offer to us for UG-5-AFR-24V-ST2 please contact us.

Where can I buy UG-5-AFR-24V-ST2 by Calectro in Turkey?

You can purchase UG-5-AFR-24V-ST2 by Calectro from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.

What is the price of the UG-5-AFR-24V-ST2?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Calectro in Turkey?

While we are not the official distributor or seller of Calectro in Turkey, we source our products from reliable channels and offer you original Calectro equipment at competitive prices.

How can I access UG-5-AFR-24V-ST2 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for UG-5-AFR-24V-ST2 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for UG-5-AFR-24V-ST2?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
