Prices R27-2176-NK-035/055-4-8 (OEM) Dietz-Motoren Turkey

BRAND	Dietz-Motoren
Product	R27-2176-NK-035/055-4-8 (OEM)
Internal code	OZH1783935
Weight	38
Technical specification	Engine torque 4.69 / 3.69 Nm Output torque 128-128-52 / 128-128-41 Nm Engine rpm 712.5 / 1425 1 / min Output speed 7,5-22-53 / 15-34-105 1 / min Motor power 0,35 / 0,55 kW Load factor from 0.43 to 2.5 / 0.55 to 3.1 Shaft type Solid shaft with keyway Output bearing reinforced bearing Shaft dimension Ø 22x 60 VP * 210484 Housing design Feet finish Mounting position IMB3 Output shaft seal double Adjustment Handverst.links Skalensch. * Adjusting handwheel with scale housing Scale 1 - 10 * 22252 R27 + R57 Drive cone bore Ø 19 Lubrication Mobilgear 600 XP 220 * CLP ISO VG 220 Material number 846 076 size BG080 Number of poles 8/4 pole Power 0.35 / 0.55 KW Motor designation K20R80K8-4 / B20R80K8-4 Option Design Standard * Voltage fixed voltage - + 5% Circuit D / YY frequency 50Hz Voltage 400 V Ambient temperature -15 to + 40 ° C Standard Thermal class 155 (F) IP56 Thermal motor protection thermal contact NC self-ventilated Cooling S1 mode operation KLK- / connector position KLK 180 ° Cable entry left Option motor nameplate KLK and nameplate STÖBER Log Paint W / 2-Komp.Gr + 2-Comp. Deckl. Color RAL 9006 white aluminum Lackieroptionen Complete painted Documentation language German Documentation English

Dietz-Motoren - R27-2176-NK-035/055-4-8 (OEM) referenced product produced by high technology.
If you need other products from Dietz-Motoren, please send us an inquiry by e-mail. It distinguishes with price and quality among the similar products. You can find the most competitive prices about endustriel accessories in our company. Contact us if you are looking for alternative price of R27-2176-NK-035/055-4-8 (OEM) .

Where can I buy R27-2176-NK-035/055-4-8 (OEM) by Dietz-Motoren in Turkey?

You can purchase R27-2176-NK-035/055-4-8 (OEM) by Dietz-Motoren from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.

What is the price of the R27-2176-NK-035/055-4-8 (OEM)?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Dietz-Motoren in Turkey?

While we are not the official distributor or seller of Dietz-Motoren in Turkey, we source our products from reliable channels and offer you original Dietz-Motoren equipment at competitive prices.

How can I access R27-2176-NK-035/055-4-8 (OEM) catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for R27-2176-NK-035/055-4-8 (OEM) on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for R27-2176-NK-035/055-4-8 (OEM)?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
