| BRAND | Alfatronix |
| Product | PV24I 24/12V |
| Description | Converter with Isolation |
| Internal code | OZH388776 |
| Weight | 0.84 |
| Technical specification | Input voltage range17-32Vdc Output voltage 13.6Vdc +15% -20% at extremes of temperature, load, input tolerance, etc. Intermittent output power As stated, taken for a maximum of 2 minutes followed by 8 minutes rest. Transient voltage protection Meets ISO7637-2 International standard for 24Vdc commercial vehicles Electrostatic voltage protection Meets ISO10605, ISO14892, >8kV contact, 15kV discharge Output noise <50mV pk-pk (100mV on 24V units) at continuous load. Meets CISPR25 and VDE0879-3 Off load current (quiescent current) <15mA Power conversion efficiency Typically: 90% for non-isolated units, 85% for isolated units Isolation >400Vrms between input, output and case, on isolated products only Mean time between failures >162 years (HRD4) Operating temperature -25ºC to +30ºC to meet this specification table +30ºC to +80ºC de rate linearly to 0A Storage temperature -25ºC to +100ºC Operating humidity 95% max., non-condensing Casework, Anodised aluminium, glass filled polycarbonate, dust water and impact resistance to IP533 Connections Four 6.3mm push-on flat blade connectors Output indicator Red LED adjacent to output terminals Mounting method ‘Click ‘n’ fit mounting clip, fitted separately using three hole fixing Safe area protection: Over current Limited by current sensing circuit Over heat Limited by temperature sensing circuit Transients Protected by filters and rugged component selection Catastrophic failure Protected by internal input and output fuses Approvals 2004/108/EC The general EMC directive 2006/96/EC The automotive directive 93/68/EEC The CE marking directive |
Where can I buy PV24I 24/12V by Alfatronix in Turkey?
You can purchase PV24I 24/12V by Alfatronix from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.
What is the price of the PV24I 24/12V?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Alfatronix in Turkey?
While we are not the official distributor or seller of Alfatronix in Turkey, we source our products from reliable channels and offer you original Alfatronix equipment at competitive prices.
How can I access PV24I 24/12V catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for PV24I 24/12V on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for PV24I 24/12V?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
