Prices MV 5391-P RTK Regeltechnik Turkey

BRAND	RTK Regeltechnik
Product	MV 5391-P
Description	Engine control valve
Internal code	OZH3375290
Weight	1
Technical specification	W-Nr. 14052172/010 Motorregelventil - Baureihe MV 5391-P in Durchgangsform, mit Pumpenfreilauf Nennweite DN 50, Nenndruck PN 40 Gehäusewerkstoff Stahlguss EN-GP-240-GH Flansche mit Dichtfläche nach DIN Spindelabdichtung: Dachmanschetten PTFE/Kohle Kennlinie/Anström.: gleichprozentig/auf den Kegel Lochkegel mit 10 % Freilauf, gehärtet (metallisch dichtend) Kvs-Wert = 19 m³/h, Hub 30 mm Sitzdurchmesser 40 mm Oberflächenbehandlung mit Zinkstaubgrundierung mit Zeugnis nach EN 10204-3.1 CE-Kennzeichnung gemäß Druckgeräterichtlinie (PED) max. zulässiger Druck nach DIN EN 1092 max. zulässige Temperatur TS 200 °C Elektrischer Stellantrieb - Typ REact 60E-045 Stellkraft 6 kN, einschließlich Handverstellung Wechselstrommotor 230 V, 50/60 Hz Stellgeschwindigkeit 0.45 mm/s, Hub 30 mm Schutzart IP 65 ENGLISH: two-way design, with recirculation connection nominal diameter DN 50, pressure rating PN 40 body made of cast steel EN-GP-240-GH flanges according to DIN spindle packing: chevron rings PTFE/graphite characteristic / flow direction: equal % / reverse perforated cone with 10 % recirculation, hardened kvs-value = 19 m³/h, stroke 30 mm seat diameter 40 mm surface treatment with zinc dust primary coat CE-marking according PED max. allowed pressure according to DIN EN 1092 max. allowed temperature TS 200 °C Electric actuator - type REact 60E-045 actuating force 6 kN, incl. handwheel for manual operation single-phase motor 230 V, 50/60 Hz actuating speed 0.45 mm/s, stroke 30 mm protection rating IP 65 - additional limit switches (2 off)

RTK Regeltechnik - MV 5391-P referenced Engine control valve product produced by high technology.
MV 5391-P became irreplaceable of foundations. MV 5391-P referenced product which is satisfy the customer's needs, offers advantages of quality and cost. You can find the most competitive prices about endustriel accessories in our company. Contact us if you are looking for alternative price of MV 5391-P .

Where can I buy MV 5391-P by RTK Regeltechnik in Turkey?

You can purchase MV 5391-P by RTK Regeltechnik from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.

What is the price of the MV 5391-P ?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of RTK Regeltechnik in Turkey?

While we are not the official distributor or seller of RTK Regeltechnik in Turkey, we source our products from reliable channels and offer you original RTK Regeltechnik equipment at competitive prices.

How can I access MV 5391-P catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for MV 5391-P on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for MV 5391-P ?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
