Prices MV5214 W.Nr. 5122293/030 RTK Regeltechnik Turkey

BRAND	RTK Regeltechnik
Product	MV5214 W.Nr. 5122293/030
Internal code	OZH4942417
Weight	22
Technical specification	Motor control valve - MV 5214 series in continuous form nominal size DN 25, nominal pressure PN 16 Housing material ductile iron EN-GJS-400-18-LT Flanges with DIN sealing surface Spindle sealing: Bellows with PTFE safety plug Characteristic/flow rate: equal percent/below the cone parabolic cone, metallic sealing Kvs value = 1.7 m³/h, stroke 25 mm Seat diameter 8 mm Surface treatment with zinc dust primer max. allowable pressure in accordance with DIN EN 1092 max. allowable temperature TS 350 °C Electrical actuator - type ReAct 30E-028 Positioning force 3 kN, including manual adjustment 230 V 50/60 Hz AC motor Adjustment speed 0.28 mm/s, stroke 25 mm Protection class IP 65 additional equipment: - Spring clamp - additional limit switches (2 pieces) - Potentiometer 1000 ohms

RTK Regeltechnik - MV5214 W.Nr. 5122293/030 referenced product produced by high technology.
MV5214 W.Nr. 5122293/030 became irreplaceable of foundations. MV5214 W.Nr. 5122293/030 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. MV5214 W.Nr. 5122293/030 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy MV5214 W.Nr. 5122293/030 by RTK Regeltechnik in Turkey?

You can purchase MV5214 W.Nr. 5122293/030 by RTK Regeltechnik from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.

What is the price of the MV5214 W.Nr. 5122293/030?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of RTK Regeltechnik in Turkey?

While we are not the official distributor or seller of RTK Regeltechnik in Turkey, we source our products from reliable channels and offer you original RTK Regeltechnik equipment at competitive prices.

How can I access MV5214 W.Nr. 5122293/030 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for MV5214 W.Nr. 5122293/030 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for MV5214 W.Nr. 5122293/030?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
