Prices MI-DM0080 DM0802-AAM1BB083JDV-252mm Interroll Turkey

BRAND	Interroll
Product	MI-DM0080 DM0802-AAM1BB083JDV-252mm
Internal code	OZH5019400
Weight	7.11
Technical specification	Product name DM 0080 Synchron Protection level IP 69K Tube length (SL) 245.0 mm Drum width (FW) 252.0 mm Installation length (EL/LW/BF) 257.0 mm Total axle length (AGL) 282.0 mm Power 425 W Winding number of pins 8 Torque [Nm] 46.8 Band tensile force 1,145 N Gear ratio (i) 38.50 Gear material description steel: 16MnCr5/AISI 5115 Speed at frequency 1 0.33 m/s Frequency 1 200 Hz external connection diagram M90 high voltage 400 V Rated current, high voltage 1.32 A Stainless steel pipe material: 1.4301/304 Tube diameter (A) 81.7 mm Tube diameter (B) 81.7 mm Wedge steel tube shape Pipe option type wedge steel spot welded 4x4mm wedge steel pipe option Wedge steel tube length 195.0 mm Cover A standard version Cover B standard version Cover A Material stainless steel: 1.4301/304 Cover B material stainless steel: 1.4301/304 Wave A standard version Ø30mm Shaft B version standard Ø30mm Wave A material stainless steel: 1.4305/303 Wave B material stainless steel: 1.4305/303 Wave A key. Area width (F) 25.0 mm Wave B key area (F) 25.0 mm Wave A key. Surface length (C) 12.5 mm Wave B key surface length (C) 12.5 mm Oil type synthetic food oil Viscosity 150 Electrical connection straight screw connection Elec. Connection material stainless steel: 1.4301/304 Power cable length 10.0 m Power cable type shielded; halogen-free min. ambient temperature -25 °C max. ambient temperature 40 °C

Interroll - MI-DM0080 DM0802-AAM1BB083JDV-252mm referenced product produced by high technology.
You can provide the all references you look for in endustrial accessories in our company with our unique product range. It distinguishes with price and quality among the similar products. Our company can make an offer even if we do not distributor of Turkey. Contact us if you are looking for alternative price of MI-DM0080 DM0802-AAM1BB083JDV-252mm .

Where can I buy MI-DM0080 DM0802-AAM1BB083JDV-252mm by Interroll in Turkey?

You can purchase MI-DM0080 DM0802-AAM1BB083JDV-252mm by Interroll from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.

What is the price of the MI-DM0080 DM0802-AAM1BB083JDV-252mm?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Interroll in Turkey?

While we are not the official distributor or seller of Interroll in Turkey, we source our products from reliable channels and offer you original Interroll equipment at competitive prices.

How can I access MI-DM0080 DM0802-AAM1BB083JDV-252mm catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for MI-DM0080 DM0802-AAM1BB083JDV-252mm on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for MI-DM0080 DM0802-AAM1BB083JDV-252mm?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
