| BRAND | Badger Meter |
| Product | B102101 |
| Description | Einbauzähler mit Impulsgeber für Schmieröl |
| Internal code | OZH331977 |
| Weight | 1 |
| Custom code | 9028 20 00 |
| Technical specification | LM OG 1/2" BSP ALU LCP Buna 1-35 l/min with Reed contact 100 PPL Built-in counter with pulse generator for lubricating oil Materials and technical data Measuring principle: Oval wheel counter Housing: aluminum Oval wheels: plastic (LCP) Seal: Buna Measuring range: 1 - 35 l/min Measurement accuracy: ± 0.5% of the measured value Viscosity range: 8-5000 mPas p-max: 100 bar t-max: 50°C Protection class: IP 42 Connection: 1/2" BSP female thread Pulse generator (blue) Pulse output: 1x100ppl, reed |
