2140000277

KP75-MB/2-M12K WG-V140 1:1 M16-LH/M12-RH
Transmission position position - pos.11
V140 spiral bevel gearbox; i= 1:1
Same as type plate number P-716952/1
*IP64 motor and transmission (based on ATEX class II 3D Ex tc IIIB T300°C Dc - IP64).
*There is no ATEX approval for the drive concept.
*There is no ATEX approval for the drive concept.
Dimension sheet: 1NJ001659
K model series/design series: K75
Type/type: KP75-MB/2-M12K
- - Varnishing/painting - -: -
Color/colour: RAL 7031 blue grey 2K/blue grey 2K-PUR
- - Mechanical data/mechanical data - -: -

K-size sheet/dimension sheet: 1NJ001659-1
Design/mounting position: V5
K-mounting sides: one-sided foot machining
Storage AS/Bearing-AS (DE): Double bearing
Bearing BS/Bearing-BS (NDE): simple bearing
Protection class: IP64
- - Output variant -: -
Output variant: flange disc/flange plate
W.diameter/shaft diameter [mm]: 30
W. length/shaft length [mm]: 155 (center gear to start tool/middle gear to
beginning of tool)
Wave thread/shaft thread: M16-L.H. + M12-R.H.
K-flange plates Ø/ external diameter flange [mm]: 140
K-tool width [mm]: 2 - 5
- - - - Electrical data - -: -
Label/Approval|Identification/Certification: CE
Number of phases: 3~
Rated power/nominal power [kW]: 7.5
Operating mode/Duty type: S 6-60%
Number of pins/Poles: 2
Nominal motor speed/Nominal motor speed [1/min; rpm]: 2890
Rated voltage/nominal voltage [V]: 400
Rated frequency/ Nominal frequency [Hz]: 50
Rated current/Nominal current In [A]: 13.8
Circuit/ Wiring: S102 (D)
CosPhi/CosPHI: 0.9
Insulation class: F
Winding protector/ Motor protector: PTC 130°C
Supply type/power supply: network operation/mains operation
Motor circuit diagram/Motor connection diagram: A0102100
Circuit diagram built-in 1/Con. diagram compon. 1: A01TP000
- - Electr. Connection/electrical connection- -: -
K-elect.connection type/elec. connection mode: terminal box/ terminal box
KK material/Terminal box material: aluminum/aluminum
KK location/Terminal box position: 2DK
KK screw connection/gland: (2x) -M25x1.5 + (1x) -M16x1.5 + (3x) -M12x1.5
External grounding motor/External grounding motor: Not available/not existing
- - Ventilation/Ventilation - -: -
Ventilation type: E - self-ventilation/self-ventilation
- - - - brake/brake - - - - - - - - - - - -: -
Brake type/ Brake type: M12K [12Nm] (L8)
Brake control voltage [V]: 360-440
Wiring/Connection: on the clipboard/on terminal block
Brake 1 circuit diagram/Brake connection diagram 1: A01BA003
- - - - - Gearbox - - - - - - - - - - - -: -

K-gear type/K-gear type: angle gear/ angular gear V140
Transmission position/Gear position: Pos11
Translation/ratio [i]: 1
Oil type: CLP PAO 68 Synth.oil
Oil quantity [l]: 0.30
- - - - load, forces - - - -: -
Ambient temperature/ Ambient temperature /Ta [°C]: -20/+40
- - Rating plate/name plate - -: -
K-rating plate/name plate: adhesive label 90x60 /adhesive label 90x60
Rating plate logo/name plate logo: SKY
