Prices KL75.01-SB/2 Li + M12K HIMMEL Turkey

BRAND	HIMMEL
Product	KL75.01-SB/2 Li + M12K
Description	flat motor
Internal code	OZH3380585
Weight	31
Technical specification	Flachmotor KL75.01-SB/2 Li + M12K Art.Nr.2140000237 Maßblatt: 1NJ100000000143 K-Modellreihe / Design series: KL75.01 Typ / Type: KL75-SB/2-M12K K-Maßblatt / Dimension sheet: 1NJ100000000143 Farbe / Colour: RAL 6011 Resedagruen 2K / Reseda green 2K-PUR Bauform / Mounting position: B8 Schutzart / Protection class: IP54 K-Leistungsschild / Name plate: Klebeschild 29x53 Leistungsschild Logo / Name plate Logo: Himmel K-Besonderheiten 2 / specific feature 2: für FU-Betrieb ausgelegt W.Durchmesser / shaft diameter: 30,0 mm W.Länge / shaft-length: 54,0 mm (mitte Fußbohrung bis Anfang Werkzeug) Wellengewinde / shaft thread: M20 links K-Flanschscheiben Ø / external diameter flange: 120 mm K-Werkzeugbreite / tool width: max. 3 mm KK-Ausführung / Terminal box type: Aluminium-M25 / aluminium-M25 KK-Lage / Terminal box position: 3B Elektrische Ausführung / Elektrical design: CE Leistung / Power [kW]: 3.7 Motordrehzahl / Motor speed [1/min; 1/rpm]: 2900 Frequenz / Frequency [Hz]: 50 Phasenanzahl: 3~ Spannung / Voltage [V]: 230/400 Strom / Current [A]: 13.40/7.60 CosPhi / CosPhi: 0.86 Schaltung / Wiring: S100 (D/Y) Betriebsart / Duty type: S1 Wicklungsschutz / Motor protector: 3WT`s 160°C Isolationsklasse / Insulation class: F Schaltbild Motor / Connection diagram motor: A0100000 Schaltbild Einbauten 1 / Con. diagram compon. 1: A01TB000 Bremstyp / Brake type: M12K [12Nm] (L8) Bremssteuerspg / Brake supply voltage [V]: 400 Verschaltung / Connection: nicht am Klemmbrett / not on terminal block Schaltbild Bremse 1 / Connection diagram brake 1: A01BA000

HIMMEL - KL75.01-SB/2 Li + M12K referenced flat motor product produced by high technology.
KL75.01-SB/2 Li + M12K became irreplaceable of foundations. It distinguishes with price and quality among the similar products. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. Contact us if you are looking for alternative price of KL75.01-SB/2 Li + M12K .

Where can I buy KL75.01-SB/2 Li + M12K by HIMMEL in Turkey?

You can purchase KL75.01-SB/2 Li + M12K by HIMMEL from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.

What is the price of the KL75.01-SB/2 Li + M12K?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of HIMMEL in Turkey?

While we are not the official distributor or seller of HIMMEL in Turkey, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.

How can I access KL75.01-SB/2 Li + M12K catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for KL75.01-SB/2 Li + M12K on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for KL75.01-SB/2 Li + M12K?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
