Prices G052.001601.010.009.010 24V DC GSR Turkey

BRAND	GSR
Product	G052.001601.010.009.010 24V DC
Description	Solenoid valve
Internal code	OZH4823518
Custom code	84818073
Technical specification	Reference A52440606T012NT consists of: 052.001601 2/2-way solenoid valve Tipo: A5244/0606/T012-NT Control type: directly controlled, required pressure difference: 0 bar Construction: seat valve with nipple seal Function: NO - opened without electricity Connection: G1/4" nominal size: 3.0 mm Pressure: 0 - 10 bar Temperature (medium): -10°C/+130°C Temperature (ambient): -10°C/+35°C Viscosity max.: 22 mm²/s Material (housing): stainless steel 1.4305 Material (internal parts): stainless steel 1.4104 Seal: EPDM Installation: drive in an upright or horizontal position Note: NT = valve is opened without current, and .: suitable for media temperatures up to 130°C B0051.000779 with magnetic coil Type: T012 Voltage: 24V DC Dust/water protection: IP65 Power: 18.5 watts Duty time: 100% ED Connection type: device plug in accordance with DIN 43650-A ISO4400 B0040.000047 Standard plug without circuitry, unassembled in a plastic bag Cable socket: 28x28mm Standard: in accordance with EN175301-803 Form A Cable pressure screw: M20 x 1.5 Possible connection cables: Ø5 - 8mm/Ø8 - 10mm Max. cable cross section: 1.5mm² Voltage: 0 - 250V AC/DC Max. current: 10 A Temperature range: -40 to + 90 °C Housing material: PA6 GF/black Fire protection class: HB-UL94 housing and contact carrier

You can find the current prices belongs to GSR - G052.001601.010.009.010 24V DC coded Solenoid valve product. You can provide the all references you look for in endustrial accessories in our company with our unique product range. Our company supply G052.001601.010.009.010 24V DC referenced product fastest and securest on your request. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for G052.001601.010.009.010 24V DC GSR . G052.001601.010.009.010 24V DC referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.
