Prices G040.002484.090.009.090 GSR Turkey

BRAND	GSR
Product	G040.002484.090.009.090
Description	Selenoid valve
Internal code	OZH3416784
Weight	1
Custom code	84818073
Technical specification	for connection to 230V 50-60HZ Reference D40250801.032XX consisting of: 10 pcs 040.002484 D4025/0801/.032 0.3-20bar G1 10 pcs B0051.000161 Mag.032 230V~50-60Hz15vaIP65 10 pcs B0040.000047 GST28 ForMa Standard 2/2-way valve Type: D4025/0801/.032 Control type: servo-controlled, required delta-p: 0.3 bar Construction: membrane Function: NC - closed without current Connector: G1 Nominal size: 25mm Pressure: 0.3 - 20 bar Medium temperature: -10°C/+80°C Ambient temperature: -10°C/+35°C Viscosity max.: 22 mm²/s Medium:... Material (housing): stainless steel 1.4581 Material (internal parts): stainless steel 1.4104 (AISI 430 F) Seal: NBR Installation position: horizontal or upright drive with magnetic coil Type: .032 (K0510390) Voltage: 230V/50-60Hz Pulling capacity: 28 VA Holding power: 50Hz 18VA/60Hz 15VA Protection class: IP65 Duty time: 100% ED Connection type: device plug in accordance with DIN 43650-A ISO4400 with device plug 28 x 28 mm, in accordance with DIN 43650, unassembled in a plastic bag Cable fitting: M20x1.5 connectable cables: Ø6-9mm max.1.5mm² Standard: EN 175301-803 Form A/ISO 4400 Voltage: 250V AC or DC Output: max 1.5A Temperature (ambient): -40°C/+90°C .: Housing material PPA6 GF30 .: Sealing: NBR (black) - profile seal GDM 3-16 .: Dipped steel screw

GSR - G040.002484.090.009.090 referenced Selenoid valve product produced by high technology.
You can ask all the codes and references except G040.002484.090.009.090 too. All of the listed products are with guaranteed origin and high quality. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. G040.002484.090.009.090 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.
