Prices G027.002606.010.009.010 GSR Turkey

BRAND	GSR
Product	G027.002606.010.009.010
Description	2/2 way solenoid valve
Internal code	OZH4293545
Weight	4
Custom code	84818071
Technical specification	for connection to 24V DC Reference: E27030401.692NQ consists of: 027.002606 2/2 way solenoid valve Item name: E2703/0401/.692-NQ Control type: forced, differential pressure at least 0 bar Construction: diaphragm valve Function: NO - open de-energized Connection: ANSI 150 lbs flanges seat: 25 mm pressure: 0 - 16 bar Temperature (medium) ፦10°C/+80°C Temperature (environment) ፦10°C/+35°C Viscosity (max): 22 mm²/sec Material (housing): cast iron EN-JL 1040 Material (media affected): stainless steel 1.4104/brass 2.0401 seal: NBR Installation: drive in upright position Option: NQ = AF + HA + NO .: AF = flanges according to Class 150 ASME B 16.5 .: HA = manual operation .: NO = open de-energized B0051.000499 with solenoid Type: 1692 (K0516910) Voltage: 24V DC Dust/water protection: IP65 power: 25W Duty cycle: 100% ED Connection type: device plug according to DIN 43650-A ISO4400 B0040.000047 device plug 28 x 28 mm, according to DIN 43650, unassembled in a plastic bag Cable gland: M20x1.5 Connectable cables: diameter 6-9 mm max.1.5 mm² Standard: EN 175301-803 form A/ISO 4400

GSR - G027.002606.010.009.010 referenced 2/2 way solenoid valve product produced by high technology.
G027.002606.010.009.010 became irreplaceable of foundations. G027.002606.010.009.010 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. Contact us if you are looking for alternative price of G027.002606.010.009.010 .

Where can I buy G027.002606.010.009.010 by GSR in Turkey?

You can purchase G027.002606.010.009.010 by GSR from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.

What is the price of the G027.002606.010.009.010?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of GSR in Turkey?

While we are not the official distributor or seller of GSR in Turkey, we source our products from reliable channels and offer you original GSR equipment at competitive prices.

How can I access G027.002606.010.009.010 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for G027.002606.010.009.010 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for G027.002606.010.009.010?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
