| BRAND | Pieper |
| Product | FKS-1401-C07-180 |
| Internal code | OZH4799537 |
| Weight | 0.36 |
| Custom code | 85444995 |
| Technical specification | Hybrid Cable SO.-LAN element: 4x2x0.15mm² Conductor: 19x0.10mm tinned Core Insulation: FEP Diameter: Nom. 1.30 mm Core colors: white/orange, white/green, white/blue, white/brown Twisted Pairs: Each 2 cores twisted pair Shielding: ST film per couple Element Distribution: 4 Stranded 4 Shieldet Pairs Together Shielding: ST movie over Stranding Shielding: Copper Braid vz. Coverage: app. 85% density, 0.12 mm wires Intermediate Casing: Silicone Element 4x0.25 mm²: Conductor 0.25 mm²: 14 x 0.15 mm tinned Insulation: silicone Core colors: red, blue, white, yellow Element Distribution: Stranded 4 Cores Each + Movie Element 3x0.25 mm²: Conductor: 14x0.15mm tinned. Insulation: silicone Core colors: red, blue, white Element Distribution: Stranded 3 cores each + movie Element 5x0.75 mm²: Conductor: 24x0.20mm tinned Insulation: silicone Core colors: black, brown, blue, green, green/yellow Element Distribution: Stranded 5 Cores Each + Movie Main distributor: So.-LAN Element + Stranded 3 Elements together with Filler + Film Shielding: Copper Weave tinned app. 85% density Casing: silicone Casing color: black similar to RAL 9001 Outer diameter: 17.0mm +/- 0.30mm Rated Voltage: 300/300 Volts (0.75 mm²) Peak operating voltage: 250 volts (0.25 mm²) Temperature range: -50°C - +180°C (static) -25° - +180°C (dynamic) Net weight [kg]: 0.36 |
Where can I buy FKS-1401-C07-180 by Pieper in Turkey?
You can purchase FKS-1401-C07-180 by Pieper from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.
What is the price of the FKS-1401-C07-180?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Pieper in Turkey?
While we are not the official distributor or seller of Pieper in Turkey, we source our products from reliable channels and offer you original Pieper equipment at competitive prices.
How can I access FKS-1401-C07-180 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for FKS-1401-C07-180 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for FKS-1401-C07-180?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
