Prices FCA 112 M-2 / PHE (S3) AC Motoren Turkey

Q: Where can I buy FCA 112 M-2 / PHE (S3) by AC Motoren in Turkey?

You can purchase FCA 112 M-2 / PHE (S3) by AC Motoren from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.

Q: What is the price of the FCA 112 M-2 / PHE (S3)?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Q: Who is the official distributor or seller of AC Motoren in Turkey?

While we are not the official distributor or seller of AC Motoren in Turkey, we source our products from reliable channels and offer you original AC Motoren equipment at competitive prices.

Q: How can I access FCA 112 M-2 / PHE (S3) catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for FCA 112 M-2 / PHE (S3) on our website. Visit our resources section or contact us directly for specific documents.

Q: Do you provide technical support for FCA 112 M-2 / PHE (S3)?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

BRAND	AC Motoren
Product	FCA 112 M-2 / PHE (S3)
Description	three-phase asynchronous motor
Internal code	OZH4680824
Weight	25.5
Custom code	85015220
Technical specification	Motor power: 5.24 kW/6.29 kW Number of motor poles: 2 Motor voltage: 3 x 230/400 V +- 10%, 50 Hz 3 x 265/460 V +- 10%, 60 Hz Motor speed: 2905 min-1/50 Hz 3486 min-1/60 Hz Rated motor current: 16.97/9.76 A Efficiency class: IE3 Efficiency: 88.1 - 88.1 - 86.3% at 4/4 - 3/2 - 2/4 load Cos phi: 0.88 Protection class: IP 55 Insulation class: F Operating mode: S3 - 10% Weight: 25.5 kg Design: IM B5 (flange version) flange size: 250 x 215 x 180 mm Motor shaft: 28 m6 x 60 mm Terminal box position: above Coolant temperature: -20 to +40 °C Installation height: < 1000 m above sea level Colour: RAL 7030 stone grey aluminum housing Additional equipment: without suitable for frequency control

You can find the current prices belongs to AC Motoren - FCA 112 M-2 / PHE (S3) coded three-phase asynchronous motor product. You can provide the all references you look for in endustrial accessories in our company with our unique product range. All of the listed products are with guaranteed origin and high quality. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for FCA 112 M-2 / PHE (S3) AC Motoren . Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.
