Prices DIC-4-002-E-0000-03 Demag Turkey

BRAND	Demag
Product	DIC-4-002-E-0000-03
Description	frequency converter
Internal code	OZH4871216
Weight	1.3
Technical specification	Dedrive Compact STO igital two-point inverter with voltage link for one and four-quadrant operation with integrated Brake chopper for resistance braking. Integrated “Safe Torque Off” (STO) safety function in accordance with EN 61800-5-2. Fulfilled the requirements Cat.3, PLd according to EN ISO 13849-1 and SIL2 according to IEC 61508. Technical data: Line voltage: 3 x 380 - 480 V (+10/-15%) Network frequency: 50/60 Hz (+10/-10%) Motor shaft power: 0.75 kW Output voltage: 3 x 0 - line voltage V Output frequency: 0 - 300 Hz depending on the switching frequency Output current: 2.4 A at 2 to 8 kHz Overload factor at 2 and 4 kHz: 1.5 for 60 s; 2.0 for 10 s (cycle 10 min) Modulation frequencies: 2, 4, 8, 12, 16 kHz (note current reduction) Protection class: IP 20 Operating temperature: 0 - 40 °C Installation height: 0 - 1000 m Dimensions: 60/190/175 mm width/height/depth Installation position: vertical Line voltage: 3 x 400 V Output current: 2.4 A at 40 °C ambient temperature and 4 kHz modulation frequency Overload factor: 1.5 for 60 s (cycle 10 min.) 2.0 for 10 s (cycle 10 min.) Operating temperature: 0 °C/40 °C Installation height: 0/1000 m specification: Type: Dedrive Compact STO DIC-4-002-E-0000-03

You can find the current prices belongs to Demag - DIC-4-002-E-0000-03 coded frequency converter product. You can ask all the codes and references except DIC-4-002-E-0000-03 too. We are one of the few companies which can present an offer for this product. It produced result of tests of laborotory for years. DIC-4-002-E-0000-03 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy DIC-4-002-E-0000-03 by Demag in Turkey?

You can purchase DIC-4-002-E-0000-03 by Demag from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.

What is the price of the DIC-4-002-E-0000-03?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Demag in Turkey?

While we are not the official distributor or seller of Demag in Turkey, we source our products from reliable channels and offer you original Demag equipment at competitive prices.

How can I access DIC-4-002-E-0000-03 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for DIC-4-002-E-0000-03 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for DIC-4-002-E-0000-03?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
