| BRAND | Honsberg |
| Product | CRG-025HMS |
| Description | flow monitor |
| Internal code | OZH1249486 |
| Weight | 0.81 |
| Custom code | 85365080 |
| Technical specification | 940423 - Honsberg location Goods number: 90261089 Tipo: CRG Nominal size: For DN 25.. 200 Connection: R1- DIN 2999 Connection type: screw-in thread Body: brass Paddle: set - 4 paddles Pressure resistance: PN 11 Media temperature: -20.. +120 °C Ambient temperature: -20.. +85 °C Switching range: Depending on the nominal diameter Switch head: ABS/PC transparent cover El. Connection: cable M20x1.5, on the side of the hood El. Contact: micro switch El. Contact material: silver Contact rating: 250 V AC 15 (8) A Connection diagram: Changer - No. 0.374 Protection class: IP 65 Flow direction: Horizontal from left |
