Prices BNA-EN20/16/B1-M2,300-L60x2-MRF-ZTS190/PN16/A110 Ksr Kuebler Turkey

BRAND	Ksr Kuebler
Product	BNA-EN20/16/B1-M2,300-L60x2-MRF-ZTS190/PN16/A110
Internal code	OZH5096708
Weight	40
Custom code	90261089
Technical specification	BNA-EN20/16/B1-M2,300-L60x2-MRF-ZTS190/PN16/A110 Bypass level indicator type BNA-S00 Pressure: 1 bar; temperature: -10°C... 330 °C; density, medium: 880 kg/m³ Test pressure: 3 bar Chamber dimensions: 60.3 x 2 mm stainless steel 1.4401/1.4404 (316/316L) Process connection: flange DIN EN 1092-1 DN 20 PN 16 form B1 Center distance: 2300 mm Measurement range: 2300 mm Chamber closure at the top: tube base Lower chamber closure: Flange D130 Drain: G 1/2" plug Swimmer: ZTS190/PN16/A110 Display: BMD-FA, aluminum profile with stainless steel flaps Damping element: damping spring at the bottom with cover Seal (s): Sigraflex Universal Pro Screws: stainless steel A4-70 (M) Overhang above (T): 100 mm Bottom overhang (U): 200 mm Distance from bottom process connection to outlet end: 260 mm (max.) Side distance (X): 100 mm (maximum) Type plate: laser marked aluminum Weight: 16.9 kg

Ksr Kuebler - BNA-EN20/16/B1-M2,300-L60x2-MRF-ZTS190/PN16/A110 referenced product produced by high technology.
BNA-EN20/16/B1-M2,300-L60x2-MRF-ZTS190/PN16/A110 became irreplaceable of foundations. All of the listed products are with guaranteed origin and high quality. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for BNA-EN20/16/B1-M2,300-L60x2-MRF-ZTS190/PN16/A110 Ksr Kuebler . We present you the most competative price and delivery time on BNA-EN20/16/B1-M2,300-L60x2-MRF-ZTS190/PN16/A110 referenced product.

Where can I buy BNA-EN20/16/B1-M2,300-L60x2-MRF-ZTS190/PN16/A110 by Ksr Kuebler in Turkey?

You can purchase BNA-EN20/16/B1-M2,300-L60x2-MRF-ZTS190/PN16/A110 by Ksr Kuebler from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.

What is the price of the BNA-EN20/16/B1-M2,300-L60x2-MRF-ZTS190/PN16/A110?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Ksr Kuebler in Turkey?

While we are not the official distributor or seller of Ksr Kuebler in Turkey, we source our products from reliable channels and offer you original Ksr Kuebler equipment at competitive prices.

How can I access BNA-EN20/16/B1-M2,300-L60x2-MRF-ZTS190/PN16/A110 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for BNA-EN20/16/B1-M2,300-L60x2-MRF-ZTS190/PN16/A110 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for BNA-EN20/16/B1-M2,300-L60x2-MRF-ZTS190/PN16/A110?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
