Prices Art.Nr.: HW43,Type 1242A Fischer Mess Regeltechnik Turkey

Q: Where can I buy Art.Nr.: HW43,Type 1242A by Fischer Mess Regeltechnik in Turkey?

You can purchase Art.Nr.: HW43,Type 1242A by Fischer Mess Regeltechnik from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.

Q: What is the price of the Art.Nr.: HW43,Type 1242A ?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Q: Who is the official distributor or seller of Fischer Mess Regeltechnik in Turkey?

While we are not the official distributor or seller of Fischer Mess Regeltechnik in Turkey, we source our products from reliable channels and offer you original Fischer Mess Regeltechnik equipment at competitive prices.

Q: How can I access Art.Nr.: HW43,Type 1242A catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for Art.Nr.: HW43,Type 1242A on our website. Visit our resources section or contact us directly for specific documents.

Q: Do you provide technical support for Art.Nr.: HW43,Type 1242A ?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

BRAND	Fischer Mess Regeltechnik
Product	Art.Nr.: HW43,Type 1242A
Internal code	OZH3340924
Weight	18
Technical specification	Art. Nr.: HW43 Produktgrp.: Ventile Industry control valve with actuator Type1124: Industry control valve with electric actuator Closing pressure: 3150kPa Two-way valve BR 225 Type 1242A Type 1242A: Two-way valve BR225 Body:Spheroidal graphite GGG-40.03 EN-JS1024 Connection type: Flanges acc. EN1092-2 Type 21 Form B1 Diameter nominal:DN 40 Pressure nominal: PN16-40 kvs-value: 25m3/h Stroke: 20mm Characteristic: A-AB equal percentage Direction of flow: flow to open Leakage rate: EN1349 - seat-leakage IV L 1 (< 0.01% of kvs- value) Plug: Parabolic plug made of CrNi-steel 1.4057 Sreat: Pressed seat made of 1.4021 Seat diamter: 40mm Stem sealing: VE04.6 PTFE lip rings Protective coating: 1K-zinc-rich primer, grey Medium: Water-Glycol max. temperature TS:0...+180°C Tech.terms of delivery:1349/PED 2014/68/EU Kat. I with CE marking 0045 Actuator connector:Thread M10 for MCxx3 / PA-N160 / PA-N300 Electric linear acuator MC 503 Type 1922E Type 1922E:Electric linear actuator MC503 Power supply: AE03.2 115 V AC Frequency: 50-60 Hz Acuating thrust: 5kN Acuating time: 2,5 s/mm Input signal:0...10 V DC Output signal:0...10V DC Enclosure protection: IP54 Elec. connection: Terminal Actuator stroke:<= 30mm Attachment: For valves DN15 - DN65 M10 stroke 20mm-30mm Actuator equipment:AE05.1 Actuator heater

Fischer Mess Regeltechnik - Art.Nr.: HW43,Type 1242A referenced product produced by high technology.
Art.Nr.: HW43,Type 1242A is the result of a far more developed technology compared to similar regular products. Art.Nr.: HW43,Type 1242A referenced product which is satisfy the customer's needs, offers advantages of quality and cost. Our company can make an offer even if we do not distributor of Turkey. Make an offer to us for Art.Nr.: HW43,Type 1242A please contact us.

Where can I buy Art.Nr.: HW43,Type 1242A by Fischer Mess Regeltechnik in Turkey?

You can purchase Art.Nr.: HW43,Type 1242A by Fischer Mess Regeltechnik from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.

What is the price of the Art.Nr.: HW43,Type 1242A ?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Fischer Mess Regeltechnik in Turkey?

While we are not the official distributor or seller of Fischer Mess Regeltechnik in Turkey, we source our products from reliable channels and offer you original Fischer Mess Regeltechnik equipment at competitive prices.

How can I access Art.Nr.: HW43,Type 1242A catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for Art.Nr.: HW43,Type 1242A on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for Art.Nr.: HW43,Type 1242A ?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
