BRAND	AC Motoren
Product	ACM 160 L2 / PHE
Description	1 IE3 three-phase motor
Internal code	OZH4547633
Weight	160
Custom code	85015230
Technical specification	Motor power: 18.50 KW number of motor poles: 2 motor voltage: 3 x 400/690 V +- 10%, 50 Hz 3 x 460/795 V +- 10%, 60 Hz Motor speed: 2940/3528 RPM Rated motor current: 32.47/18.82 A cos phi: 0.89 Efficiency class: IE3 Efficiency: 92.4 - 92.4 - 90.6 & at 4/4 - 3/2 - 2/4 load Degree of protection: IP 55 Insulation class: F Weight:142kg Design: foot version IM B3 Motor shaft: 42 m6 x 110 mm terminal box location: top Coolant temperature: -20 to +40 °C Installation height: < 1000 m above sea level Colour: RAL 7030 stone grey cast iron housing Customs tariff number 85015230 Additional equipment: 3 built-in PTC sensors suitable for frequency control further technical data and dimensions according to the catalog

AC Motoren - ACM 160 L2 / PHE referenced 1 IE3 three-phase motor product produced by high technology.
ACM 160 L2 / PHE became irreplaceable of foundations. All of the listed products are with guaranteed origin and high quality. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. Our established relationships with producers from all around the world and their official representatives helps us to meet your needs for spare parts, machinery, consumables and other products of the industrial field.
