| BRAND | Neuenhauser-Vorwald |
| Product | 0655676 |
| Description | Tension shaft 403 L ø 75 |
| Internal code | OZH4673088 |
| Weight | 55 |
| Custom code | 84799020 |
| Technical specification | Drawing No. 403/71388/1/0600 INDEX 0 pneumatically expanding Design for the following technical data: Roll width (one-nut) max. 1350 mm Roll weight max. 2240 kg Roll width (one-nut) 900 mm Roll weight max. 1494 kg Roll width (one nut) min 675 mm Maximum roll weight: 1120 kg Roll width (cut) max. 1350 mm Roll weight max. 1020 kg Roll width (cut) 900 mm Roll weight max. 910 kg Roll width (cut) min 675 mm Maximum roll weight 840 kg Roll diameter 1300 mm Track speed 600 m/min 600 N train Winding sleeve diameter 3"=76.2 mm Cardboard wrapping sleeve material Structural design of the tensioning shaft Type of actuation pneumatic, internal expansion hose Valve position 1 piece, radial Support tube diameter 75 x 15 mm Material steel Set of 8 stretchers, 3 pieces around the circumference, 100 mm long, made of aluminum with screwed-on rubber strips Expansion path ø75 mm to ø 79 m Round pins set off with shaft ends Bearing distance 1660 mm Overall length 1690 mm Stress data Deflection 1.0 mm at 1350 mm working width (monotonous) 2240 kg roll weight 2.9 mm with 900 mm working width (monotonous) 1450 kg roll weight 3.1 mm at 675 mm working width (monotonous) 1120 kg roll weight 3.0 mm at 1350 mm working width (cut) 1020 kg roll weight 3.0 mm at 900 mm working width (cut) 910 kg roll weight 3.0 mm at 675 mm working width (cut) 840 kg roll weight required operating pressure 6 bar Max. allowed nk= 2282 1/min |
Where can I buy 0655676 by Neuenhauser-Vorwald in Turkey?
You can purchase 0655676 by Neuenhauser-Vorwald from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.
What is the price of the 0655676?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Neuenhauser-Vorwald in Turkey?
While we are not the official distributor or seller of Neuenhauser-Vorwald in Turkey, we source our products from reliable channels and offer you original Neuenhauser-Vorwald equipment at competitive prices.
How can I access 0655676 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 0655676 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 0655676?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
