| BRAND | Fluidtech |
| Product | 138050 |
| Description | double switch filter |
| Internal code | OZH1326340 |
| Weight | 3.5 |
| Custom code | 84212980 |
| Technical specification | DF 4.225-B20.060.l1-p-5.02-2,0-f2.2,0-z Volume (pos. net): approx. 8 dm³ 4.225 DN20 PN16 according to Znr. 4.225-020.001-Z materials: - Housing, rotary vanes and filter covers: Al - Seals: NBR Connections: - Universal steel flange - G1 outside - G3/4 inside (SAE) for screwing with 2 built-in filter elements (VA/ epoxy) - 60 μm nom./100 μm abs. with fitted differential pressure indicator type 5.02 - Measurement range up to 2.0 bar - Contact f2 at 2.0 bar - DeltaP f2 viewing window (270°) |
