| BRAND | S+S REGELTECHNIK |
| Product | 1301-1112-2010-000 |
| Description | Differential pressure transmitter |
| Internal code | OZH2894084 |
| Weight | 0.4 |
| Technical specification | Power consumption < 1 W at 24 V DC; < 2 VA at 24 V AC Voltage supply 15...36 V DC depending on working resistance, residual ripple stabilised ± 0.3 V Working resistance Ra (ohm) = (Ub -14 V)/ 0.02 A for I variant Measuring function Differential pressure, volume flow (square root output signal) Current consumption < 20 mA Measuring ranges multi-range switching with 8 switchable measuring ranges Media temperature -20...+50°C Pressure connection with connection nozzles for pressure hose Ø 6 mm Type of pressure differential pressure Zero point offset ± 5 % of final value Above- below-pressure max. 5 x pressure range Medium clean air and non-aggressive, non-combustible gases Signal filtering switchable 1 s/ 10 s Output 4...20 mA Electrical connection 2- or 3-wire connection 0.14 - 1.5 mm² via terminal screws Output signal 4...20 mA Cable connection cable gland, plastic (M 16 x 1.5; with strain relief, exchangeable, max. inner diameter 10.4 mm) or M12 connector according to DIN EN 61076-2-101 (optional on request) Cable gland M 16 x 1.5, including strain relief, exchangeable, max. inner diameter 10.4 mm Long-term stability ± 1 %/ year Hysteresis 0.3 % of final value Media contacting parts ms, Ni, Nylon, PU, Si, PVC with plasticisers Temperature drift values ± 0.1 % of final value/ °C Linearity < ± 1 % of final value Air humidity < 95 % r. H., non-precipitating air Accuracy (1000 Pa): ± typically 10 Pa compared to the calibrated reference device Protection class III (according to EN 60 730) Protection type IP 65 (according to EN 60 529)* Standards CE conformity, electromagnetic compatibility according to EN 61326, according to EMC Directive 2014/ 30/ EU Measuring range pressure 0 ... +100 Pa / -100 ... +100 Pa 0 ... +300 Pa / -300 ... +300 Pa 0 ... +500 Pa / -500 ... +500 Pa 0 ... +1000 Pa / -1000 ... +1000 Pa Housing plastic, UV-stabilised, material polyamide, 30 % glass-globe reinforced, with quick-locking screws (slotted/ Phillips head - combination), colour traffic white (similar to RAL 9016), housing cover for display is transparent ! Housing dimensions 72 x 64 x 43.3 mm (Tyr 1 with Display) Features two-line display with illumination, cutout approx. 36 x 15 mm (W x H), to display ACTUAL pressure |
Where can I buy 1301-1112-2010-000 by S+S REGELTECHNIK in Turkey?
You can purchase 1301-1112-2010-000 by S+S REGELTECHNIK from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.
What is the price of the 1301-1112-2010-000?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of S+S REGELTECHNIK in Turkey?
While we are not the official distributor or seller of S+S REGELTECHNIK in Turkey, we source our products from reliable channels and offer you original S+S REGELTECHNIK equipment at competitive prices.
How can I access 1301-1112-2010-000 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 1301-1112-2010-000 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 1301-1112-2010-000?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
