Prices 046.000062 GSR Turkey

BRAND	GSR
Product	046.000062
Description	2/2-way solenoid valve
Internal code	OZH1223833
Weight	1
Technical specification	2/584-21-0806-1702 1-110 bar reference 2584B000 Type: 2/584-21-0806-1702 (2584B000) Control type: servo-controlled, required delta-p: 1 bar Construction: Plunger valve Function: NC - closed without power Connection: G1/4 Nominal size: 8 mm Pressure: 1 - 110 bar Medium temperature: -60°C/+80°C Ambient temperature: -20°C/+35°C Viscosity max.: 22 mm²/s Material (housing): stainless steel 1.4571 (AISI 316) Material (inner parts): stainless steel 1.4104 (AISI 430 F) Seal: EPDM Installation position: horizontal or upright drive Note: Marking the housings with pressure, connection, .: manufacturer, material, flow direction with arrow, .: with RC element, with magnetic coil for connection to 24V DC Remarks: Adapter with LED display (mounted between coil and plug) .: VBS LED 24V DC/AC only LED 28x28 B0051.000522 solenoid coil Type: .702 (K0517010) Voltage: 24V DC Dust/water protection: IP65 Power: 25W Switch-on time: 100% ED Connection type: device plug in accordance with DIN 43650-A ISO4400 B0040.000047 Device plug 28 x 28 mm, in accordance with DIN 43650, unassembled in a plastic bag Cable fitting: M20x1.5 connectable cables: Ø4.5-11mm max.1.5mm² Standard: EN 175301-803 Form A/ISO 4400 Voltage: 250 V AC or DC Output: max. 1.5A Temperature (environment): -40°C/+90°C

GSR - 046.000062 referenced 2/2-way solenoid valve product produced by high technology.
046.000062 is the result of a far more developed technology compared to similar regular products. We are one of the few companies which can present an offer for this product. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. 046.000062 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy 046.000062 by GSR in Turkey?

You can purchase 046.000062 by GSR from Özhat İç ve Dış Tic. Ltd. Şti.. We serve customers across Turkey, offering competitive prices and reliable service.

What is the price of the 046.000062?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of GSR in Turkey?

While we are not the official distributor or seller of GSR in Turkey, we source our products from reliable channels and offer you original GSR equipment at competitive prices.

How can I access 046.000062 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 046.000062 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 046.000062?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
